40 Sonata Series — Planning and Installation Manual
Section 2 — Planning Guide
Table 2. Sonata-to-Maestro Mix Over Input Mapping
Sonata Input Connector Signal Name Maestro Input
A1 Input 1 (L&R) Mix Over A Ch. 1&2
A2 Input 2 (L&R) Mix Over A Ch. 3&4
A3 Input 3 (L&R) Mix Over A Ch. 5&6
A4 Input 4 (L&R) Mix Over A Ch. 7&8
A5 Input 5 (L&R) Mix Over A Ch. 9&10
A6 Input 6 (L&R) Mix Over A Ch. 11&12
A7 Input 7 (L&R) Mix Over A Ch. 13&14
A8 Input 8 (L&R) Mix Over A Ch. 15&16
B9 Input 9 (L&R) Mix Over B Ch. 1&2
B10 Input 10 (L&R) Mix Over B Ch. 3&4
B11 Input 11 (L&R) Mix Over B Ch. 5&6
B12 Input 12 (L&R) Mix Over B Ch. 7&8
B13 Input 13 (L&R) Mix Over B Ch. 9&10
B14 Input 14 (L&R) Mix Over B Ch. 11&12
B15 Input 15 (L&R) Mix Over B Ch. 13&14
B16 Input 16 (L&R) Mix Over B Ch. 15&16
C17 Input 17 (L&R) Mix Over C Ch. 1&2
C18 Input 18 (L&R) Mix Over C Ch. 3&4
C19 Input 19 (L&R) Mix Over C Ch. 5&6
C20 Input 20 (L&R) Mix Over C Ch. 7&8
C21 Input 21 (L&R) Mix Over C Ch. 9&10
C22 Input 22 (L&R) Mix Over C Ch. 11&12
C23 Input 23 (L&R) Mix Over C Ch. 13&14
C24 Input 24 (L&R) Mix Over C Ch. 15&16
D25 Input 25 (L&R) Mix Over D Ch. 1&2
D26 Input 26 (L&R) Mix Over D Ch. 3&4
D27 Input 27 (L&R) Mix Over D Ch. 5&6
D28 Input 28 (L&R) Mix Over D Ch. 7&8
D29 Input 29 (L&R) Mix Over D Ch. 9&10
D30 Input 30 (L&R) Mix Over D Ch. 11&12
D31 Input 31 (L&R) Mix Over D Ch. 13&14
D32 Input 32 (L&R) Mix Over D Ch. 15&16
