Sonata Series — Planning and Installation Manual 45
Interfacing to Apex
Output Mapping for the Sonata MADI to AES Outputs from Apex
The MADI outputs of the Apex Router have a fixed channel assignment.
These channels can not be changed or remapped. However, the mode the
Apex router is running can change how the signals are addressed from the
control system.
B16 AES Pair 16 Right Input 32
C17 AES Pair 17 Left Input 33
C17 AES Pair 17 Right Input 34
C18 AES Pair 18 Left Input 35
C18 AES Pair 18 Right Input 36
C19 AES Pair 19 Left Input 37
C19 AES Pair 19 Right Input 38
C20 AES Pair 20 Left Input 39
C20 AES Pair 20 Right Input 40
C21 AES Pair 21 Left Input 41
C21 AES Pair 21 Right Input 42
C22 AES Pair 22 Left Input 43
C22 AES Pair 22 Right Input 44
C23 AES Pair 23 Left Input 45
C23 AES Pair 23 Right Input 46
C24 AES Pair 24 Left Input 47
C24 AES Pair 24 Right Input 48
D25 AES Pair 25 Left Input 49
D25 AES Pair 25 Right Input 50
D26 AES Pair 26 Left Input 51
D26 AES Pair 26 Right Input 52
D27 AES Pair 27 Left Input 53
D27 AES Pair 27 Right Input 54
D28 AES Pair 28 Left Input 55
D28 AES Pair 28 Right Input 56
D29 AES Pair 29 Left Input 57
D29 AES Pair 29 Right Input 58
D30 AES Pair 30 Left Input 59
D30 AES Pair 30 Right Input 60
D31 AES Pair 31 Left Input 61
D31 AES Pair 31 Right Input 62
D32 AES Pair 32 Left Input 63
D32 AES Pair 32 Right Input 64
