to transfer it to. You can import rules or group them to be activated or deactivated as
a batch. Clicking the Rules tab displays the Rules pane if it is covered by other panes.
Managed Channels pane: Displays all the currently configured record and play
channels on K2 systems that can be controlled through the Dyno PA application. If
you have administrator-level privileges on Dyno PA, you can add, edit, or delete
channels in addition to playing, recording, stopping, fast-forwarding, rewinding, or
ejecting assets or putting an asset in loop playback mode. Clicking the Managed
Channels tab displays the Managed Channels pane if it is covered by other panes.
Recording Assets pane: Displays all the records currently in progress on the K2
systems. You can view the records in list or thumbnail view, browse a record or load
it to one of the K2 systems. The tabs above the record trains let you choose whether
to view record trains on one K2 system or all available systems. Clicking the Recording
Assets tab displays the Recording Assets pane if it is covered by other panes.
Transfer Scheduler pane: Displays the scheduled transfers. You can add, edit, cancel,
delay or delete scheduled transfers in this pane. You can save a scheduled transfer as
an .xml file and load it later. Clicking the Transfer Scheduler tab displays the Transfer
Scheduler pane if it is covered by other panes.
Browse pane:Allows you to load assets from a K2 Summit system and view them in
Dyno PA. You can create markers, mark in or mark out points, create subclips, unload
the asset or locate it in the Asset List, and activate Live mode. You can also lock the
keyboard or external control by using the keyboard/control button.
Info pane: Allows you to view the video and keyword information of a highlighted
asset. The
Properties button lets you access the Advanced Asset Properties, which
holds information out the asset, its metadata, links, rules and track information. Clicking
the Info tab displays the Info pane if it is covered by other panes. In this pane, clicking
the Locate button causes the Asset List pane to display the bin on the K2
system where the asset loaded in the Info pane is located.
Active Transfer pane: Allows you to view transfers currently in progress as well as
failed transfers, if any. Clicking the Active Transfer tab displays the Active Transfer
pane if it is covered by other panes.
Completed Transfer pane: Allows you to view the status of completed transfers.
Clicking the Completed Transfers tab displays the Completed Transfer pane if it is
covered by other panes.
Quick Logging pane: Allows you to associate Dyno PA tags and markers (tags linked
to a specific timecode) with assets or remove them from assets. You can also add,
edit, delete or export Dyno PA keywords from categories. Clicking the Quick Logging
tab displays the Quick Logging pane if it is covered by other panes.
Markers pane: Lets you view Dyno and Dyno PA tags and markers as they are created
or edited. You can filter the tags and markers or view by recorded or counter timecode.
