14
Setting Up the Kaleido-IP Multi-Viewer
XEdit Installation 2
The Local Area Connection Properties window opens.
3. On the Networking tab, under This connection uses the following items, click Internet Protocol
Version 4 (TCP/IPv4), and then click Properties.
The Internet Protocol Version 4 (TCP/IPv4) Properties window opens.
4. On the General tab, click Use the following IP address.
5. Type an IP address in the same range as the default management IP address of the multi-viewer. For
example, if the IP address of the multi-viewer is 10.0.3.70, then the IP address of your client PC could
be 10.0.3.123. If you are unsure, contact your network administrator.
6. Type a subnet mask in the same range as that of the Kaleido-IP.
7. Click OK.
8. In Local Area Connection Properties, click OK.
Step 3: XEdit Installation
The Kaleido-X Layout Editor (XEdit) is used to create layouts and configure the multi-viewer. When the
computer with XEdit is connected to the multi-viewer through a TCP/IP network, you can use XEdit to
modify layouts and settings directly on the multi-viewer, or you can work locally on the computer and then
export your changes to the multi-viewer.
XEdit is not provided as a standalone application. You download the application to your client PC or laptop
directly from the multi-viewer.
To install XEdit:
1. From a workstation on the same subnet as the multi-viewer, open a Web browser window and type
the IP address of the multi-viewer in the address bar.
The Kaleido-X home page appears.
Note: You can also download XEdit from the Miranda Technical Support portal. Contact
[email protected] for details.
