6
Abmessungen . Dimensions . Dimensions . Dimensioni . Dimensiones
8.5
63
M12 x 0.5
6.4
Ø 32.2
Ø 49
40
Ø 54.3
41
+ 30° Abstrahlbereich
+ 30° transmission range
+ 30° Plage de transmission
+ 30° Campo di irradiazione
+ 30º Campo de irradiación
TS 440
Tolerancing ISO 8015
ISO 2768 - m H
< 6 mm: ±0.2 mm
