12. tsA500 tecHnIcAl detAIls
InPuts
INPUT
impedance: 500 Kohm, max. voltage: 10 Vpp
RETURN EFFECT impedance: 22 Kohm, max. voltage: 15 Vpp
controls
GAIN (TUBE SECTION)
-80 dB to +35 dB range
GAIN (SOLID STATE SECTION) -45 dB to +28 dB range
LINE OUT level control on front paneL
PRE/POST EQ (FOR BOTH LINE OUT) switch on rear panel
GROUND LIFT (FOR LINE OUT) switch on rear panel
GROUND LIFT (FOR LINE OUT AUX) switch on rear panel
MASTER VOLUME
PHONES LEVEL
FOOTSWITCH
eQuAlIZAtIon
LOW
center frequency: 60 Hz; level: ±16 dB
MID LOW (semi-parametric) frequency 100 to 800 Hz; level: ±16 dB
MID HIGH (semi-parametric) frequency 700 Hz to 6 kHz; level: ±16 dB
HIGH center frequency: 4.5 kHz; level: ±16 dB
VLE (VINTAGE LOUDSPEAKER EMULATOR) max cut range: 250 Hz to 20 kHz
VPF (VARIABLE PRE-SHAPE FILTER) center frequency 380 Hz (cut)
outPuts
SEND EFFECT
unbalanced, max. voltage 12 Vpp
TUNER OUT unbalanced, max. voltage 2 Vpp
LINE OUT balanced XLR, max. voltage 25 Vpp
LINE OUT AUX balanced XLR, max. voltage 25 Vpp
SPEAKER OUT speakon, 1/4”
PHONES OUT 30 to 600 ohm, max. voltage 10 Vpp
otHer
HEIGHT
2 rack units (3.36 in. / 86 mm)
WIDTH 14.21 in. / 36.8 cm (19.01 in. / 48.3 cm
with rack ears)
DEPTH 11.9 in. / 30.2 cm
WEIGHT 7.5 lbs / 3.4 kg
OUTPUT POWER 300W RMS @ 8 ohm, 500W RMS @ 4
ohm
PoWer reQuIrement 100; 120V; 230V; 240V 50/60Hz
(Voltage is factory reset according to
region of sale)
fuse
EUROPE
4 A 250V T 5x20
AUSTRALIA/UK 4 A 250V T 5x20
USA/CANADA 8 A 250V T 5x20
JAPAN 10 A 250V T 5x20
