Description of operation
The wet and dry vacuum cleaner is
equipped with a robust stainless steel
container for waste collection. The guiding
wheels and castors make the appliance
very easy to manoeuvre. The suction
flow is switched off by a float during wet
vacuuming once the waste tank is full. In
addition, the machine has a blower func-
tion and a socket for the connection of a
further electrical appliance.
The following describes the function of the
operating parts.
See the front fold-out page for
illustrations.
Overview
Housing
1 Carrying handle
2 Mains power cable
3 Motor housing
4 Sealing clip
5 Collector
6a 2 feet with wheels and acces-
sory fittings
6b 2 feet with castors and acces-
sory fittings
7 Drainage outlet
8 Suction connection
9 Appliance socket
10 On/off switch
Filter
.
11 Fluted filter (11a) and filter
cover (11b) for dry vacuuming
(already installed)
12 Paper filter bag for fine dust
13 Foam filter for wet vacuuming
. Accessories
14 Accessory bag
15 Handle with air regulation
16 Two-part vacuum tube
17 Vacuum tube holder
18 Vacuum hose
19 Powertool hose
20 Powertool reduction adaptor
piece
for connecting electrical equip-
ment for dust extraction.
. Nozzles
21 Switchable household nozzle
for vacuuming carpets
for vacuuming smooth sur-
faces
22 Crevice nozzle
23 Cushion nozzle
24 Car nozzle
25 Retaining bracket for suction
hose
Assembly
Unpack the machine and check that it is
complete (see overview). Dispose of the
packaging properly.
Pull out the mains plug.
Danger of electric shock.
1. Attach the feet (6) to the hous-
ing.
- The feet with wheels (6a)
numbered
+
must
be fitted into the appropriate
adaptors on the rear side of
the waste collector (see
small picture a).
- The feet with guide rollers
(6b) must be fitted to the hold-
