34 GB/MT
Radio­controlled weather station
Intended use
The weather station displays the indoor and out-
door temperatures in Celsius (°C) or Fahrenheit
(°F), the indoor air humidity in percent (% RH) and
their maximum and minimum values. The weather
station also displays the weather forecast, the time
in 12 / 24-hour clock modes and the date. The
weather station also displays the sunrise and sunset
times for that day and the phase of the moon.
In addition, the weather station has an alarm and
calendar function. The device is not intended for
commercial use.
Description of parts
and features
Weather station
1 Weather symbol
2 Barometric pressure bar display
3 Indoor air temperature
4 Comfort indicator
5 Air humidity (%RH) (indoor)
6 Moon phase
7 Moon rise / set
8 Location
9 Sunrise / sunset
10 ALARM button
11 / button
12 SNOOZE / LIGHT button
13 Alarm icon
14 / 12 / 24 button
15 MODE button
16 Date (year, month, day)
17 Time display
18 Radio tower symbol
19 Barometric pressure of previous hour
20 Absolute / relative barometric pressure
21 Temperature trend (outdoor)
22 Selected channel
23 Battery state indicator
24 Outdoor temperature
25 Barometric pressure trend
26 Channel button (CHANNEL)
27 HISTORY / WEATHER button
(Weather data memory)
28 “+“ / °C / °F button
29 “–“ / MAX / MIN button
30 Relative / absolute barometric pressure button
31 SUN / MOON button (Sun / moon)
32 Wall mounting hole
33 Reset button
34 Battery compartment
35 Stand
Sensor
36 Control LED
37 Outdoor temperature / outdoor sensor channel
38 Wall mounting hole
39 Channel selector switch
40 Battery compartment
41 °C / °F button
42 TX button (“Channel setting button”)
43 Stand
Technical data
Weather Station:
Temperature range:
0 – +50 °C
+32 – +122 °F
Temperature resolution: 0.1 °C
Humidity
measurement range:
20 –99 %
Humidity resolution: 1 %
Radio signal: DCF
Battery: 3 x AA 1.5 V
(Mignon, LR06, included
in scope of supply)
Dimensions: 230 x 150 x 30 mm
(B x H x D)
Outdoor Sensor:
Temperature
measurement range:
–20 – +50 °C
–4 – +122 °F
HF transmission signal: 433 MHz
HF transmission range: approx. 100 m
in open spaces
Battery: 2 x AAA 1.5 V
(Micro, LR03, included
in scope of supply)
Scope of supply
1 x weather station
1 x outdoor sensor
3 x battery AA 1.5 V (Mignon, LR06, pre-installed)
2 x dowel (dia. approx. 6 mm)
2 x screw
2 x battery AAA 1.5 V (Micro, LR03 pre-installed)
1 x operating instructions
Safety
YOU SHOULD STORE ALL SAFETY INFOR-
MATION AND INSTRUCTIONS IN A SAFE
PLACE IN CASE YOU NEED TO REFER TO
THEM AGAIN IN THE FUTURE!
General safety information
DANGER
TO LIFE AND ACCIDENT
HAZARD FOR TODDLERS
AND SMALL CHILDREN! Never allow
children to play unsupervised with the packag-
ing material. There is a danger of suffocation
from the packaging material. Children frequently
underestimate the dangers. Children should
be kept away from the product at all times.
Children or persons who lack the knowledge or
experience to use the device or whose physical,
sensory or intellectual capacities are limited
must never be allowed to use the device without
