POWXQG7510 EN
Copyright © 2014 VARO P a g e | 9 www.varo.com

Before mowing, remove all foreign objects from the lawn which may be thrown by the
machine. While mowing, stay alert for any foreign objects which may have been missed.

Never lift the rear of the mower while starting the motor or during normal operation.

Never place your hands or feel underneath the floor pan or into the rear discharge chute
while the motor is running.
9 STARTING
Before connecting up the lawn mower to the electric power supply, make sure that the mains
supply voltage is 230-240 V~50 Hz. When the lawn trimmer power on the indicator light will
turn on. (Fig 7) Start the motor as follows:
 Press the safety push-button. (3)
 And meanwhile, pull the the switch handle, and keep it in grasp. (2)
Once the motor is running, push the lawn mower manually.
If you release the switch handle, the motor will stop.
CAUTION! The blade starts turning as soon as the motor is started.
WARNING! Cutting elements continue to rotate after the motor is switch off.
CAUTION! The equipment is suitable for use only in a power supply which
permissible modulus of system impedance is 0.320
Ω or less.
9.1 For the best results when mowing
Clear lawn of debris. Be sure that the lawn is clear of stones, sticks, wire or other foreign
objects which could be accidentally thrown out by the mower in any direction and cause
serious personal injury to the operator and others as well as damage to property and
surrounding objects. Do not cut wet grass. For effective mowing do not cut wet grass because
it tends to stick to the underside of the deck preventing proper mowing of the grass clippings.
Cut no more than 1/3 the length of the grass. The recommended cut for mowing is 1/3 the
length of the grass. Ground speed will need to be adjusted so the clippings can be dispersed
evenly into the lawn. For especially heavy cutting in thick grass it may be necessary to use
one of the slowest speeds in order to get a clean well mowed cut. When mowing long grass
you may have to cut the lawn in two passes, lowering the blade another 1/3 of the length for
the second cut and perhaps cutting in a different pattern than was used the first time.
Overlapping the cut a little on each pass will also help to clean up any stray clippings left on
the lawn. The mower should always be operated at full throttle to get the best cut and allow it
to do the most effective job of mowing. Clean underside of deck. Be certain to clean the
underside of the cutting deck after each use to avoid a build-up of grass, which would prevent
proper mulching. Mowing leaves. The mowing of leaves can also be beneficial to your lawn.
When mowing leaves make sure they are dry and are not laying too thick on the lawn.
Do not wait for all the leaves to be off the trees before you mow.
WARNING: if you strike a foreign object, stop the engine and wait until
cutting device has come to a complete standstill. Thoroughly inspect the
mower for any damage and repair the damage before restarting and
operating the mower. Extensive vibration of the mower during operation is
an indication of damage. The unit should be promptly inspected and
repaired.
