20 GB
Kitchen Mixer Tap
Introduction
Congratulations on the purchase of your
new product. You have selected a high
quality product. The assembly and oper-
ating instructions are part of this product. Please
carefully read these assembly instructions/instruc-
tions for use before use and observe all instructions.
These installation instructions and instructions for
use contain important installation, set-up and care
information. Please retain these installation instruc-
tions/instructions for use and hand them on to any
future owner.
Intended use
The product is only designed to regulate the hot
and cold water flow. It is only intended to be in-
stalled in sink units.
Suitable for use with all pressure-resistant hot water
systems such as central heating, continuous-flow
water heater, pressure boiler etc. This product is not
suitable for low pressure water heaters or pressure-
free small storage reservoirs, e.g. wood- or coal-
burning domestic hot water heaters, oil or gas-fired
hot water heaters, or open electrically heated cylin-
ders. When in doubt please consult a plumber or
heating specialist. Any use not specified or product
modification is prohibited and will result in damage.
Any form of use other than the stipulated intended
purpose can cause danger to life and cause injury.
The product is for private use only and is not in-
tended for medical or commercial use. The manu-
facturer accepts no responsibility if the intended
purpose of this unit is not adhered to.
Parts description
1 Fitting
2 Fitting base seal
3 C sealing washer
4 C metal washer
5 Threaded bolts
6 Locknut*
7 2 flexible connecting hoses
8 2 Union nuts with seal*
9 Handle*
10 Locking screw*
11 Hot/cold plaque*
12 Cartridge cover ring*
13 Cartridge lock nut*
14 Cartridge*
15 Aerator*
16 Spout*
17 Socket head wrench
* preinstalled
Technical Data
Connections: G ⅜“
Service pressure: min. 1.5 bar – max. 10 bar
Flow at 3 bar: approx. 10 L / min, varies by
water temperature
Scope of delivery
1 Kitchen Mixer Tap 1
1 Fastening kit ( 2 – 6 )
2 Flexible connecting hoses with seal ⅜“ ( 7 – 8 )
1 Socket head wrench 17
1 Instructions for assembly/operation
Safety information
DANGER TO
LIFE AND RISK OF ACCIDENTS
FOR INFANTS AND CHILDREN!
Never leave children unattended with the pack-
aging material. Suffocation hazard. Keep this
product well away from children. This product
is not a toy.
BEWARE OF ELECTRIC SHOCK!
Leaking or water discharge can
lead to life-threatening danger due
to electric shock. Carefully check that all
