12 GB/IE
there is a risk of overloading the
components and fire!
note: When connecting the two
ends of the LED strip using an
eight-pin plug, be sure to match
up the VCC-GND-GND-D0 and
VCC-GND-GND-DI marks at the
ends of the LED strips.
Shortening the LED
strip (see fig. C)
The LED strip
2
may be trimmed
to size. It can be cut with scissors
at the marked position, as shown
in Fig. C. The trimmed sections
can then be connected as shown
in figure C.
DangER
To LIfE BY ELECTRIC
ShoCk! Before performing any
work, first disconnect the light
from the mains power. Unplug the
power supply
3
from the socket.
Connect as described below:
Remove the protective film
from the double-sided adhe-
sive strip at the ends of the
LED strip sections being con-
nected.
Then firmly press the end of
the one LED strip onto the
pins on the connector
1
so
they pierce the strip conduc-
tor of the LED strip.
note: Be sure to match up
the VGGD mark on the
connector with the VCC-
GND-GND-D0 and VCC-
GND-GND-DI mark on the
LED strip.
Then push a plastic clip
11
onto this new connection
from the top.
note: Be sure the plastic
clips lock in to establish a
secure connection.
Repeat this process to estab-
lish a contact for the other
end of the connector.
note: Unlike the LED strip,
the connector can be moved
in any direction:
The product
has delicate solder points.
Do not route the LED strip
around corners and do not
kink. The solder points may
otherwise be damaged,
