24 GB/MT
Safety Information / Preparation / Before installation / Installation
J Fit the light in such a way to ensure it is protect-
ed from damp and dirt.
Q Preparation
Q Required tools and materials
The tools and materials mentioned are not included
in the delivery. The details and values given are non-
binding and for guidance only. The nature of the ma-
terial depends on the individual circumstances on site.
– Pencil / Marking tool
– Voltage tester
– Crossed screwdriver
– Electric drill
– Drill (ø 6 mm)
– Edge cutter
– Ladder
– Hammer
Q Before installation
Important: the electrical connection must be
made by a qualified electrician or a person author-
ised to perform electrical installations. This person
must be familiar with the properties of the light and
all connection regulations.
J Before installation, please familiarise yourself
with the instructions and illustrations in this
operating manual and with the light itself.
J Make sure before installation that there is no
voltage on the line you will be connecting the
light to. To do this, remove the fuse or switch
off the circuit breaker in the fuse box (0 position).
J Check that there is no voltage using a voltage
tester.
Q Installation
Note: you will need an electric drill to install the light.
CAUTION! RISK OF INJURY! Please read
the operating instructions for your drill.
j Remove the screws 2 on the side of the
connection enclosure 9 .
j Remove the mounting stirrup 3 from the
connection enclosure 9 .
j Mark the positions for the drilled holes on the
ceiling using the predrilled holes in the mount-
ing stirrup
3 as a guide.
j Now drill the fixing holes.
CAUTION! Ensure that you do not damage
any cables in the ceiling.
j Insert the dowels 1 into the drilled holes.
j Fix the mounting stirrup 3 to the ceiling with
the screws 4 .
j Now connect the connection cable of the light
to the mains connection cable (external)
6 by
means of the terminal block 5 .
Note: Ensure that each wire of the mains
connection cable (external)
6 is properly con-
nected in the correct place: live wire, black or
brown = symbol L, neutral wire, blue = symbol N,
protective earth wire, green-yellow = symbol .
j Fix the light to the mounting stirrup 3 with the
screws 2 .
Note: Use a clean, fluff-free cloth when you
are inserting a bulb
8 .
j Insert the bulb 8 turn it a ¼ turn clockwise.
Check that it is correctly seated.
Your light is now ready for operation.
Q Directing the spots
CAUTION! RISK OF BURNS! Change the
orientation of the spotlights 7 only when the lamp
has been switched off and the lamp head has com-
pletely cooled down.
j Turn the individual spotlights 7 in the desired
direction.
Note: The spotlights
7 can be turned
through approx. 330°.
j Tilt the individual spotlights 7 to the desired
angle.
Note: The spotlights
7 can be tilted through
approx. 90°.
