13 GB/IE 13
GB/IE
Installation
on “Installing the floor light in soil
or wooden substrates” (see Fig. I).
Your light is now ready for operation.
Q
replacing the
rechargeable batteries
Replace the rechargeable batteries when
you notice that the period of illumination
provided by the light has considerably
reduced over time, despite full exposure
to solar radiation.
note: Ensure that you switch off the
light before you replace the rechargeable
batteries.
note: To do this you will require a
Phillips screwdriver and an Allen key.
j Now follow steps 3 to 5 of the
section on “Installing the floor light
in soil or wooden substrates”.
j Remove the defective rechargeable
batteries from the battery compart-
ment
11 (see Fig. C).
j Insert 2 new rechargeable batteries
(NiMH, 1.2 V , AA) into the
battery compartment
11 .
note: Make sure you fit the batteries
the right way round (polarity). The
correct polarity is shown inside the
battery compartment.
j Place the solar cell 7 back into the
light body 5 and fix it in position
with the screws 6 (direction of
rotation ) (see Fig. D).
j If necessary release the screws 13
(in the case of installation in a con-
crete substrate).
j Switch the light on by pressing the
ON/OFF switch 10 .
j If necessary fix the light body 5
and floor insert 12 together with
the screws 13 (in the case of instal-
lation in a concrete substrate).
j Follow steps 8 to 9 of the section
on “Installing the floor light in soil
or wooden substrates”.
