22 GB/MT
Introduction
tabletop mister
Q Introduction
Familiarise yourself with the product be-
fore using it for the first time. In addition
please refer carefully to the operating
and assembly instructions and to the safety advice
set out below. Use the product only as described
and for the indicated purpose. Keep these instruc-
tions in a safe place. If you pass the product on to
anyone else, please ensure that you also pass on
all the documentation.
Q Normal use
The tabletop mister is intended to provide
atmospheric lighting and humidify the air in indoor
environments. With the help of ultrasonic waves it
creates a fine mist which looks like smoke. The LEDs
of the tabletop mister automatically change their
colour. Any use other than that previously described
or any change to the product is not permitted and
may lead to injuries and / or damage to the product.
The manufacturer does not assume any liability for
damage arising from improper use. The product is
solely intended for private and not for commercial use.
Q Description of Parts
1 Glass sphere
2 Mains lead
3 Connection plug
4 Glass sphere stand
5 Marking line
6 Holder (for mist generator)
7 Retainer (for attachment)
8 Mist generator
9 Water level sensor
10 Attachment
11 Max. mark
12 Rubber seal
13 Mains adapter
14 Adapter plug
15 LEDs
16 Ceramic disc
17 Mist generator holder
Q technical Data
tabletop mister:
Max. filling volume:
approx. 1600 ml
Temperature of the liquid
to be filled in:
5 – 50 °C
Mist generator:
Operating voltage:
24 V ~
Power: 22 W
Protection class:
Mains adapter:
Model:
GLA24-1000
Input voltage: 230 – 240 V ∼, 50 Hz
Output voltage: 24 V ∼, 1000 mA
Protection class:
Q Included in delivery
Note: When opening the packaging, please make
sure not to accidentally throw away assembly ma-
terials. Please check immediately on unpacking that
the delivery is complete and that the product and
all parts are in perfect condition. Do not under any
circumstances assemble the product if the delivery
is incomplete.
1 glass sphere
1 glass sphere stand
1 mist generator with holder and mains lead
1 stand (for mist generator)
1 plastic attachment
1 mains adapter
1 assembly and operating instructions
