Preparations... / Maintenance and Cleaning / Replacing the fluorescent tube
cables 7 before inserting the mains plug of the
power supply cable 12 into the socket.
note: Make sure that you only connect a maximum
of 10 linked-up under-cabinet lights of the same
type to one socket.
1. Install up to 10 lights of the same model next
to each other. To do so, follow steps 1 – 5 of
the section called “Mounting the light”.
note: Make sure that the distance between
the lights is not more than 24 cm.
2. Remove the protective head guard 6 by
unscrewing the screw.
3. Insert the connecting cable 7 into the con-
necting socket 5 of the light.
4. Insert the second connection of the connecting
cable 7 into the socket 1 of the other light.
5. Insert the connection of the power supply
cable 12 into the socket 1 of the first light.
6. Insert the the mains plug of the power supply
cable 12 into the socket. Your light is now
ready to use.
Q Switching On / Off
j Switch the ON / OFF switch 2 to turn the light
on or off.
Q Directing the light
j Never change the direction of the light while it
is switched on.
CAUtIOn! DAnGEr OF BUrnS! Do not
touch bulb components or bulbs as they can
reach temperatures higher than 90 °C during
operation.
j Allow the light to cool down completely.
j Turn the strip light 9 into the desired direction.
The strip light can pivot through approx. 80°
when mounted under a cabinet (mounting
holes
8 ). When fastened to a wall (mounting
holes 4 ) it can pivot through approx. 165°.
Q Maintenance and Cleaning
c CAUtIOn! DAnGEr OF ELECtrIC
SHOCK! Pull the mains plug of the power
supply cable
12 out of the socket.
WArnInG! DAnGEr tO LIFE BY
ELECtrIC SHOCK! For electrical safety the
light must never be cleaned with water or other
liquids, or immersed in water.
J Do not use solvents, petrol etc.
j Use a dry fluff-free cloth when you are cleaning.
Q replacing the fluorescent tube
c CAUtIOn! rISK OF ELECtrIC SHOCK!
Remove the mains plug of the power supply
cable
12 from the socket.
WArnInG! rISK OF BUrnS! Allow the
lamp to cool down completely (At least
10 minutes).
note: Use a clean, lint-free cloth when replac-
ing the fluorescent tube.
j Only use 230 V ~ T5 fluorescent tubes with a
maximum output of 13 W.
j Pull the protective glass 10 out of the guide
rails on both sides. Carefully lay the protective
glass
10 to one side.
j Turn the used fluorescent tube 11 a quarter
turn and pull it out of its socket.
j Carefully insert the new fluorescent tube into
the socket and give it a quarter turn until it
clicks into place.
j Check that the fluorescent tube is correctly in
place.
j Push the protective glass 10 (smooth side
should be facing outward) back into the guard
rails.
j Swivel the strip light 9 into the desired position.
m CAUtIOn! Please note that all under-cabinet
lights have to be linked together by means of
the connection cable
7 before the mains plug
of the power supply cable 12 is inserted into
the socket.
j Insert the mains plug of the power supply
cable
12 into the socket. Your light is now
ready for use.
