Commissioning
Mounting the light
Note: The product includes two different
types of screw. Use the short round-head
screws (length: 14 mm) for mounting on to
wood. Use the long countersunk head
screws (length: 28 mm) and the dowels
1
for mounting on to a solid masonry wall.
Mount the light only underneath wall cup-
boards or on the wall. The light is not suitable
for mounting on a corner or u-profile.
1. Measure up the wall or mounting surface
before drilling the holes. Use a ruler to
improve accuracy.
2. Mark the two mounting holes at a distance
of 570 mm apart.
Steps 3 and 4 apply only to mounting
on to solid masonry:
3. Now drill the fixing holes (approx. ø 5 mm,
depth approx. 30 mm). Make sure that
you do not damage any electrical cables
during this operation.
4. Insert the supplied dowels 1 into the
drilled holes.
5. Fix the under-cupboard light in place
with the screws 3 (see Fig. B).
6. Place the caps 4 on the screw heads.
7. Insert the connector plug of the mains
lead 5 into the light connector socket 6 .
8. Insert the mains plug of the mains lead
into the mains socket.
Your light is now ready for operation.
Connecting lights together
CAUTION! First ensure that all the under-
cupboard lights are connected by connection
leads
14 before inserting the mains plug of
the mains lead 5 into the mains socket.
Note: Ensure that no more than three
under-unit lights of the same type are con-
nected together in series.
Install up to three lights of the same type
close to one another. Follow steps 1 to 6
of the section on „Mounting the light“.
Note: Make sure that the distance
between the lights is not more than 20 cm.
Remove the protective cap from the con-
nection socket 8 by screwing out the
screws anticlockwise using a crosshead
screwdriver.
Plug the connection lead 14 into the
connection socket of the light.
