Preparation

Preparation

Before using these devices you must

insert the batteries,
synchronise the system code for the

remote control

1

and the remote

controlled socket

7

using the DIP

switch

6

,

10

and

allocate a ON/OFF button pair

3

,

4

on the remote control

1

to a

remote controlled socket

7

.

Preparing the remote

control

Open the battery compartment on

the back of the remote control

1

by pushing away the battery com-
partment cover

5

downwards and

then up.

Insert two enclosed batteries AAA.
Press one of the ON/OFF buttons

3

,

4

to test whether the remote

control

1

works. If it does, the

power indicator light

2

will come

on. If this light is not lit then the
device is not receiving any energy
from the batteries. Check if the
batteries are in the right way.

Close the battery compartment.

Synchronise the
system code

To use this device for the first time the sys-
tem code must be synchronised by using
the DIP switch

6

,

10

in order for all

the remote controlled sockets

7

to react

to the remote control‘s

1

radio signal.

Each remote controlled socket

7

must be

assigned to a button pair on the remote
control

1

so that each remote controlled

socket

7

can be operated separately.

Note: Change the position of the DIP
switch

6

,

10

with a suitable item, e.g.

a small screw driver with which the DIP
switch

6

,

10

can be push upwards or

downwards.

Inputting the system

code into the remote
control

Open the battery compartment on

the back of the remote control

1

by pushing away the battery com-
partment cover

5

downwards and

then up.

With the DIP switch

6

put in any

system code with the number 1 to 5.

Close the battery compartment.

Inputting the system

code into the remote
controlled socket

Turn the screws

12

of the cover

11

with a crosshead screw driver size
PH0.

Remove the cover

11

above the

compartment of the DIP switch

10

.

With the DIP switch

10

put in the

same system code as the remote
control

1

with the number 1 to 5.
