Multi-Function Detector
Intended use
This device is intended for the detection of metal,
wood and live wires. The instrument is not intended
for commercial use.
Description of parts
1 Measurement point
2 Display
3 Material switch STUD / AC WIRE / METAL
(wood/AC wire/metal)
4 MODE button
5 Stud button
6 READ button
7 M button (save)
8 Vial
9 Function switch LASER / DETECTOR /
DISTANCE
10 RM button (read memory)
11 Stud button
12 + / =-button
13 Battery compartment
14 PUSH button
15 Laser beam opening
16 Ultrasonic sender / receiver
