3
ASSEMBLY INSTRUCTIONS
BADMINTON SET
ITEM 78201-14
2. NET ATTACHMENT
A. Unscrew the Locking Net Bolts (#7), insert Locking Net Bolts through the hole in the top and middle pole,
securing with bolt nut. Note: Make sure the hooks of Locking Net bolt in the top pole is facing up, on the
middle pole is facing down.
See FIG. 2.
B. Insert Connecting Cord Loop through the gromment on each corner of net.
See FIG. 2A.
C. Attach the Connecting Cord Loop to the hook of Locking Net Bolt.
See FIG. 2B & See FIG. 2C.
FIG. 2
7
7
Locking Net Bolt
Locking Net Bolt
Bolt Nut
Top
Cable
Bottom
Cable
Gromment
Net(#12)
FIG. 2C
12
FIG. 2B
12
FIG. 2A
6
