RISCO Group Industrial LuNAR - Manual

Conducting LuNAR Self Test
1. Press the button to activate the
LuNAR self test; test results appear on the LCD:
2. Use the up or down arrows to
scroll up/down the list to view the desired results.
>
>
Self Test
ACTION LCD DISPLAY
XX indlicates the microwave x-band frequency according to the following list:
00 10.525 GHz for BE, DK, ES, GR, IT, NL, PT, SE only!
UK 10.687 GHz for UK
FR 9.9 GHz for AT, CZ, FR, FI only!
DE 9.35 GHz for Germany
Turning OFF the RC
Ordering Information:
5
Industrial LuNAR DT Detector
Industrial LuNAR Remote Control
RK200DT00XXA
RK200RC0000A
Part Number Description
PS input xxxV(9.0V-16.0V)
PIR CH1 DC level XX
PIR CH1 noise level XX
PIR CH2 DC level XX
PIR CH2 noise level XX
PIR CH3 DC level XX
PIR CH3 noise level XX
MW level XX
MW noise XX
ACTION LCD DISPLAY
Controlling the LEDs
1. Press the button to enable the LEDs.
The following message appears: LED On
Settings were
updated
LEDs disabled
Enable LEDs
4
Settings were
updated
LEDs disabled
Disable LEDs
2. Press to confirm and transmit your selection.
The following message appears:
3. Press the button to disable the LEDs.
The following message appears:
4. Press to confirm and transmit your selection.
The following message appears:
Select
LED Off
Select
NOTE:
The first line of the LCD display indicates the current status of
the LEDs.
ACTION LCD DISPLAY
Controlling the ACT Mode
NOTE:
The RC automatically shuts itself, 60 seconds from the last key
pressing, to save battery energy.
Settings were
updated
Settings were
updated
ACT is enabled
Disable ACT
ACT is disabled
Enable ACT
The following message appears:
2. Press to confirm and transmit your selection.
The following message appears:
3. Press the button to disable the ACT mode.
The following message appears:
ACT Off
4. Press to confirm and transmit your selection. Select
Select
NOTE:
In the ACT mode, the Detector switches to MW detection only,
when room temperature equals body temperature, or during a
cloaking attempt.
NOTE:
The first line of the LCD display indicates the current status of
the ACT mode.
To turn off the RC device, simply press the button again. On
© RISCO Group 12\09 5IN200RCUM C
Industrial LuNAR
Remote Control
Instructions
RISCO Group Warranty
RISCO Group. and its subsidiaries and affiliates(“Seller”) warrants its products to be free from
defects in materials and workmanship under normal use for 24 months from the date of
production.
Because Seller does not install or connect the product and because the product may be used
in conjunction with products not manufactured by the Seller, Seller can not guarantee
the performance of the security system which uses this product. Seller’s obligation and liability
under this warranty is expressly limited to repairing and replacing, at Seller’s option,
within a reasonable time after the date of delivery, any product not meeting
the specifications. Seller makes no other warranty, expressed or implied, and makes no
warranty of merchantability or of fitness for any particular purpose.
In no case shall seller be liable for any consequential or incidental damages for breach of this
or any other warranty, expressed or implied, or upon any other basis of liability whatsoever.
Seller’s obligation under this warranty shall not include any transportation charges or costs of
installation or any liability for direct, indirect, or consequential damages or delay. Seller does
not represent that its product may not be compromised or circumvented; that the product
will prevent any persona; injury or property loss by burglary, robbery, fire or otherwise; or that
the product will in all cases provide adequate warning or protection.
Buyer understands that a properly installed and maintained alarm may only reduce the risk
of burglary, robbery or fire without warning, but is not insurance or a guaranty That such will
not occur or that there will be no personal injury or property loss as a result.
Consequently seller shall have no liability for any personal injury, property damage or other
loss based on a claim that the product fails to give warning. However, if seller is held liable,
whether directly or indirectly, for any loss or damage arising from under this limited warranty
or otherwise, regardless of cause or origin, seller’s maximum liability shall not exceed the
purchase price of the product, which shall be complete and exclusive remedy against seller.
No employee or representative of Seller is authorized to change this warranty in any way
or grant any other warranty.
WARNING: This product should be test ed at least once a week.
RISCO Contacting Info
UK Tel: +44-161-655-5500 E-mail: [email protected]
ITALY Tel: +39-02-66590054 E-mail: [email protected]
SPAIN Tel: +34-91-490-2133 E-mail: [email protected]
FRANCE Tel: +33-164-73-28-50 E-mail: [email protected]
BELGIUM Tel: +32-2522-7622 E-mail: [email protected]
U.S.A Tel: +1-631-719-4400 E-mail: [email protected]
BRASIL Tel: +55-11-3661-8767 E-mail: [email protected]
CHINA Tel: +86-21-52390066 E-mail: [email protected]
POLAND Tel: +48-22-500-28-40 E-mail: [email protected]
ISRAEL Tel: +972-3-963-7777 E-mail: [email protected]
ACT On 1. Press the button to enable the ACT
mode. The following message appears:
