TILT DOWNWARD
Operation Instructions
• If you have a sliding fifth
wheel, make sure both
plungers are fully engaged.
• Inspect air line connections.
• Make sure fifth wheel is in
appropriate position for
weight distribution on the
tractor. For proper positioning
of the fifth wheel refer to
SAF-HOLLAND publication
XL-FW10008IM-en-US
available on the Internet
at www.safholland.us.
2.
Make sure coupling area is flat, level
and clear of persons and obstacles.
3.
Tilt ramps of fifth wheel downward
(Figure 3).
4. Make
sure
lock is open (Figure 4).
If lock is closed, slide release handle
forward and pull all the way out
(Figure 5). If air release equipped,
set tractor brakes and actuate fifth
wheel control valve to open lock.
6. Coupling Procedures
1. Position
the
tractor so that the center
of the fifth wheel is aligned with king-
pin and back up straight
(Figure 6).
Figure 3
Figure 4
Figure 5
Figure 6
TRAILER
(TOP)
KINGPIN
LOCK IS OPEN
LOCK IS CLOSED
PU
LL O
UT ALL
THE WAY
SLI
DE
FO
RWA
RD
