SAF-HOLLAND XL-FW313-01 XA-3501-03505 Series Yard Spotter Fifth Wheel Top Plates User Manual
Page 3
XA-3501-03505 AND XA-3501-UB PARTS BREAKDOWN
3
ITEM
NO.
ITEM
NO.
NO.
PART NO.
REQ’D.
PART NAME
NO.
PART NO.
REQ’D.
PART NAME
12
18
16
16
11
17
13
14
13
12
12
20
19
15
6
7
23
22
24
9
10
21
9
8
25
25
5
2
1
4
3
4
3
30
27
28
26
30
29
26
28
27
USED ONLY ON
XA-3501-03505
USED ONLY ON
XA-3501-03505
30
30
29
NOTE:
When replacing bracket bearings (Item 29), remove
only one bearing stop block (Item 30) from each side.
Replace bearings and install new stop blocks.
1* XA-1704-X
1 Lock
Set
2 XB-GT-13-1
1 Extension
Spring
3 XA-1313
2 Lock
Pin
4 XB-5
2 Cotter
Pin
5 XA-07295-THK 1 Yoke
6 XA-1706-1
1 Yoke
Shaft
7 XB-1505
1 Spring
8 XA-1707-5
1 Release
Handle
9 XB-PW-1732-1-116
2 Washer
10 XB-1028-1
1 Compression
Spring
11
XA-1705-7
1
Cam Plate Sub Assembly
12
XB-2083
3
Hex Hd. Cap Screw
1
⁄
2
˝20x1
3
⁄
4
˝
13 XB-T-49
2 Washer
1
⁄
2
˝
14 XA-1029
1 Roller
15 XB-T-69-A
3 Lock
Nut
16 XB-1030-1
2 Washer
17 XA-1507-1
1 Cam
Roller
18
XB-CX-58-F-134
1
Hex Hd. Cap Screw
5
⁄
8
˝18x1
3
⁄
4
˝
19 XA-2524-R-13-1 1 Air
Cylinder
20
XB-698
1
45° Street Elbow
21 XA-3528
1 Secondary
Lock
22 XB-2149
1 Torsion
Spring
23 XB-21-S-500-2750
1 Roll
Pin
24
XA-3546
1
Secondary Lock Handle
25 XB-H-38
2 Grease
Zerk
26 XB-0011
2 Rubber
Bushing
27 XB-21-S-375-1750
2 Roll
Pin
28 XA-2016
2 Bracket
Pin
29** XA-03423
2
Bracket
Bearing
30**
XA-0268
4
Bearing Stop Block
* Sold only as RK-63504.
** Used only on XA-3501-03505.
XL-FW313-01 Rev C
