Reference MVI46-103M ♦ SLC Platform
IEC 60870-5-103 Master Communication Module
ProSoft Technology, Inc. Page 85 of 187
September 12, 2006
[Section]/Item Value Range Description
Common ASDU Address: 0 to 255 This parameter sets the common ASDU
address to association with this sector of
the specified session. This parameter is
usually set the same as the data link
address when only one sector is utilized.
Online Time Sync: Y or N This parameter specifies if the sector in the
controlled device will be sent a time
synchronization command when the unit is
first recognized as being online. This
should only be utilized for devices that do
not send an EOI message after initializing.
Online General Int: Y or N This parameter specifies if the sector in the
controlled device will be sent a general
interrogation command when the unit is
first recognized as being online. This
should only be utilized for devices that do
not send an EOI message after initializing.
EOI Time Sync: Y or N This parameter specifies if the sector in the
controlled device will be sent a time
synchronization command after this module
received an EOI message from the
controlled unit.
EOI General Int: Y or N This parameter specifies if the sector in the
controlled device will be sent a general
interrogation command after this module
received an EOI message from the
controlled unit.
# ASDU Point Function Database
# Type Index Code Point
START
END
[Section]/Item Description
[IEC-103 MASTER COMMANDS] This section contains the commands for the
module
# Enable DB Poll Session Sector Data Func Point Ovrd Ovrd
# Code Index Interval Index Index Type Code Index Flag Val
START
END
Please refer to the Module Configuration section for command field definitions.
