KODAK PROFESSIONAL EKTACHROME Film E100
•
E-4000
3
PROCESSING
Chemicals
Process E-6
Push Processing Characteristics
You can increase the effective speed (i.e., push) of E100 by
adjusting the first developer time. Increased film speed is
useful under dim lighting conditions, or when you need
high shutter speeds to stop action or small lens openings
for increased depth of field. You can also use a short push
to slightly increase contrast, sharpen highlights, or
compensate for underexposure. By understanding these
effects in advance, you can use pushing creatively and
reliably.
Exposure for Push Processing
Labs that provide push processing usually offer the service
for fixed time increases (i.e. push 1/2 or push 1) in the first
developer. It is a good idea to make a series of test
exposures and then work with your lab to determine
optimum exposure settings. A recommended starting
point is to underexpose by 1 stop (EI 200) for a push 1
process (8 minutes in the first developer).
PRINTING TRANSPARENCIES
You can reproduce images made on E100 by using a variety
of KODAK PROFESSIONAL materials.
Color Prints
You can scan your image to a file and print digitally to:
• KODAK PROFESSIONAL ENDURA Premier Papers
• KODAK PROFESSIONAL ENDURA Premier Metallic
Paper
• KODAK PROFESSIONAL ENDURA Transparency
Display Material
• KODAK PROFESSIONAL ENDURA Clear Display
Material
• KODAK PROFESSIONAL ENDURA Transparency
Display Material
• KODAK PROFESSIONAL UV-Curable Display Film -
Plus
• KODAK PROFESSIONAL UV-Curable Clear Display
Film
CURVES
Diffuse rms Granularity* 8 (extremely fine)
*Read at a gross diffuse visual density of 1.0, using a
48-micrometre aperture.
Modulation-Transfer Curves
Characteristic Curves
Process:
E-6
1
10
7
5
3
2
100
70
50
30
20
200
1
2
3 4 5
10
20
50
100
200
600
SPATIAL FREQUENCY (cycles/mm)
RESPONSE (%)
B
G
R
F009_0523AC
Exposure: Daylight 1/100 second
Process: E-6
Densitometry: Status A
0.0
1.0
2.0
3.0
4.0
-3.0
-2.0
-1.0
0.0
1.0
B
G
R
LOG EXPOSURE (lux-seconds)
DENSITY
F009_0524AC
