KODAK PROFESSIONAL EKTACHROME Film E100
KODAK PROFESSIONAL EKTACHROME Film E100
Kodak Alaris Publication No. E-4000
Revised 8-18
KODAK ALARIS • ROCHESTER, NY 14615
© 2018 Kodak Alaris Inc.
The Kodak, Kodak Professional, Ektachrome, T-Grain, and Wratten Trademarks are used under license from Eastman Kodak Company.
Spectral-Sensitivity Curves
Spectral-Dye-Density Curves
Effective Exposure: 1/10 second
Process: E-6
Density: E.N.D. = 1.0
700 750 650 600 550 500 450 400 350 300 250
-2.0
-1.0
0.0
1.0
2.0
Yellow-
Forming
Layer
Magenta-
Forming
Layer
Cyan-
Forming
Layer
*Sensitivity = reciprocal of exposure (erg/cm ) required
to produce specified density
WAVELENGTH (nm)
2
LOG SENSITIVITY
*
F009_0526AC
Normalized Dyes to form a visual neutral density of 1.0
for a viewing illuminant of 5000 K
Process:
E-6
700 600 500 400
WAVELENGTH (nm)
0.0
0.4
0.6
0.2
0.8
1.0
1.4
1.2
Yellow Magenta Cyan
DIFFUSE SPECTRAL DENSITY*
F009_0527AC
NOTICE : The sensitometric curves and data in this
publication represent product tested under the conditions
of exposure and processing specified. They are
representative of production coatings, and therefore do
not apply directly to a particular box or roll of photographic
material. They do not represent standards or specifications
that must be met by Kodak Alaris. The company reserves
the right to change and improve product characteristics at
any time.
MORE INFORMATION
Kodak Alaris has many publications to assist you with
information on our products, equipment, and materials.
For the latest version of technical support publications
for KODAK PROFESSIONAL Products, visit:
www.kodakalaris.com/go/professional.
