HEIGHT
MAIN
HEIGHT
MAIN
RP-8060F
A HEIGHT
MAIN
RP-500S
A
FL
OORS
TANDING SPEAKER
REFERENCE PREMIERE WITH DOLBY ATMOS ® TECHNOLOGY
OR
CONNECTIONS
WALL MOUNTING ELEVATION SPEAKER
#10
2.5" - 3" panhead
wood screws
Mount in wall stud
or use anchors -
leave 1/4" exposed
CAUTION!
Do not use keyhole
for ceiling mounting!
The RP-500SA can be added to
any passive loudspeaker setup.
RE
CEI
VE
R
RE
CEI
VE
R
OR
RECOMMENDED
MIN. CROSSOVER:
150Hz
RECOMMENDED
MIN. CROSSOVER:
80Hz
