4. Monitoring the Unit
8784-A2-GB20-30
February 2001
4-13
Viewing LED Status
The status of the front panel LEDs can be viewed locally and remotely on the
Display LEDs status screen.
The LEDs are organized into three groups:
T
General LEDs display the status of the unit
T
DSX-1 LEDs provide the status of the DSX-1 interface
T
DSL Loop LEDs display the activity on the DSL network
To view the Display LEDs status screen, follow this menu selection sequence:
Main Menu
→
Status
→
Display LEDs
The LED status display screen is updated every 5 seconds. For information about
the meaning of the LEDs, see
main/status/leds Hotwire
Model: 8784
DISPLAY LEDs
GENERAL DSX-1 DSL LOOP
--------------------------------------------------------------------------------
ALRM:Off P1:Lnk Up P1:Lnk Up
TEST:On P2:Lnk Up P2:Lnk Up
--------------------------------------------------------------------------------
ESC for previous menu MainMenu Exit
