BAS70/ -04/ -05/ -06
Document number: DS11007 Rev. 22 - 2
3 of 4
www.diodes.com
July 2012
© Diodes Incorporated
BAS70/ -04/ -05/ -06
0.1
1
10
100
1,000
10,000
0 20 10 30 60 50 40 70
V , INSTANTANEOUS REVERSE VOLTAGE (V)
Figure 3 Typical Reverse Characteristics
R
I,
I
N
S
T
AN
T
ANE
O
U
S
R
EV
E
R
SE
C
U
R
R
EN
T
(n
A
)
R
0
0.2
0.4
0.6
0.8
1.4
1.2
1.0
1.8
1.6
0 10 5 20 25 15 35 30 40
C
,
T
O
T
AL
C
A
P
A
C
IT
A
N
C
E (
p
F
)
T
V , DC REVERSE VOLTAGE (V)
Figure 4 Total Capacitance vs. Reverse Voltage
R
Package Outline Dimensions
Please see AP02002 at http://www.diodes.com/datasheets/ap02002.pdf for latest version.
Suggested Pad Layout
Please see AP02001 at http://www.diodes.com/datasheets/ap02001.pdf for the latest version.
SOT23
Dim Min Max Typ
A 0.37 0.51 0.40
B 1.20 1.40 1.30
C 2.30 2.50 2.40
D 0.89 1.03 0.915
F 0.45 0.60 0.535
G 1.78 2.05 1.83
H 2.80 3.00 2.90
J 0.013 0.10 0.05
K 0.903 1.10 1.00
K1 - - 0.400
L 0.45 0.61 0.55
M 0.085 0.18 0.11
α 0° 8° -
All Dimensions in mm
Dimensions Value (in mm)
Z 2.9
X 0.8
Y 0.9
C 2.0
E 1.35
A
M
J L
D
F
B C
H
K
G
K1
X E
Y
C
Z
