DS30797 Rev. 6 - 2
3 of 4
www.diodes.com
DCP68/-25
© Diodes Incorporated
CAP
A
CI
T
A
NCE (
p
F
)
V , REVERSE VOLTAGE (V)
R
1
10
100
0.1
1
10
100
Fig. 8 Typical Gain-Bandwidth Product
vs. Collector Current
V
= 5V
f = 100MHz
CE
NEW PRODUCT
Ordering Information
(Note 5)
Device
Packaging
Shipping
DCP68-13
SOT-223
2500/Tape & Reel
DCP68-25-13
SOT-223
2500/Tape & Reel
Notes:
5. For packaging details, go to our website at http://www.diodes.com/datasheets/ap02007.pdf.
Marking Information
xxx
(Top View)
YWW
xxx = Product Type Marking Code:
N12 = DCP68
N12-25 = DCP68-25
YWW = Date Code Marking
Y = Last digit of year ex: 7 = 2007
WW = Week code 01 - 52
Package Outline Dimensions
SOT-223
Dim Min Max Typ
A
1.55 1.65 1.60
A1
0.010 0.15 0.05
b1
2.90 3.10 3.00
b2
0.60 0.80 0.70
C
0.20 0.30 0.25
D
6.45 6.55 6.50
E
3.45 3.55 3.50
E1
6.90 7.10 7.00
e
–— –—
4.60
e1
–—
–—
2.30
L
0.85 1.05 0.95
Q
0.84 0.94 0.89
All Dimensions in mm
