D1213A-04SO
NEW PROD
UC
T
Maximum Ratings
(@T
A
= +25°C, unless otherwise specified.)
Characteristic Symbol Value Unit Conditions
Operating Supply Voltage V
P
- V
N
6.0 V -
DC Voltage at any Channel Input - (V
N
– 0.5) to (V
P
+ 0.5) V -
Peak Pulse Current I
PP
5 A 8/20 µs, Per Figure 3
ESD Protection – Contact Discharge V
ESD_Contact
±8 kV Standard IEC 61000-4-2
ESD Protection – Air Discharge V
ESD_Air
±15 kV Standard IEC 61000-4-2
Thermal Characteristics
Characteristic Symbol Value Unit
Power Dissipation (Note 5) P D
300 mW
Thermal Resistance, Junction to Ambient (Note 5) R θJA 417 °C/W
Operating and Storage Temperature Range T
J
, T
STG
-65 to +150 °C
Electrical Characteristics
(@T
A
= +25°C, unless otherwise specified.)
Characteristic Symbol Min Typ Max Unit Test Conditions
Operating Supply Voltage V
P
— 3.3 5.5 V —
Operating Supply Current (Note 6) I
P
— — 8.0 µA (V
P
– V
N
) = 3.3V
Channel Leakage Current (Note 6) I
R
— 0.1 1.0 µA V
P
= 5V, V
N
= 0V
Reverse breakdown voltage V
BR
6.0 — — V I
R
= 1mA
Clamping Voltage, Positive Transients V
CL1
— 10.0 — V I
PP
= 1A (Note 7)
Clamping Voltage, Negative Transients V CL2
— -1.7 — V I PP = -1A (Note 7)
Forward Voltage for Top Diode V
FD1
0.60 0.80 0.95 V I
F
= 8mA, any channel to V
P
Forward Voltage for Bottom Diode V
FD2
0.60 0.80 0.95 V I
F
= 8mA, V
N
to and channel
Dynamic Resistance R DYN
— 0.9 — Ω I PP = 1A (Note 7)
Channel Input Capacitance C
T
— 0.85 1.2 pF
V
IN
= 1.65V, V
P
= 3.3V,
V
N
= 0V, f = 1MHz
Notes: 5. Device mounted on FR-4 PCB pad layout (2oz copper) as shown on Diodes, Inc. suggested pad layout AP02001, which can be found on our website at
http://www.diodes.com.
6. Short duration pulse test used to minimize self-heating effect.
7. Clamping voltage value is based on an 8x20
μs peak pulse current (I
pp
) waveform.
8. Measured from any channel to V N
9. Measured from V P to V N .
10. For information on the impact of Diodes' USB 2.0 compatible ESD protectors on signal integrity including eye diagram plots, please refer to AN77 at the
following URL: http://www.diodes.com/destools/appnote_dnote.html.
