MBR1030CT-MBR1060CT-I

Document number: DS30027 Rev. 7 - 2

2 of 4

www.diodes.com

October 2013

© Diodes Incorporated

MBR1030CT- MBR1060CT-I




Maximum Ratings (Per Leg)

(@T

A

= +25°C, unless otherwise specified.)

Single phase, half wave, 60Hz, resistive or inductive load.
For capacitive load, derate current by 20%.

Characteristic Symbol

MBR

1030CT

MBR

1040CT

MBR

1045CT

MBR

1050CT

MBR

1060CT-I

Unit

Peak Repetitive Reverse Voltage
Working Peak Reverse Voltage
DC Blocking Voltage

V

RRM

V

RWM

V

R

30 40 45

50

60 V

RMS Reverse Voltage

V

R(RMS)

21 28 31.5 35

42 V

Average Rectified Output Current (Note 5) (Per Leg)

(Total)

I

O

5

10

A

Non-Repetitive Peak Forward Surge Current
8.3ms Single Half Sine-Wave Superimposed on
Rated Load

I

FSM

100 A


Thermal Characteristics (Per Leg)

Characteristic Symbol

Value

Unit

Typical Thermal Resistance Junction to Case (Note 5)

R

θJC

3 K/W

Operating and Storage Temperature Range

T

J

,

T

STG

-55 to +150

°C



Electrical Characteristics (Per Leg)

(@T

A

= +25°C, unless otherwise specified.)

Characteristic Symbol

MBR

1030CT

MBR

1040CT

MBR

1045CT

MBR

1050CT

MBR

1060CT-I

Unit

Forward Voltage Drop Maximum
@ I

F

= 5.0A, T

C

= +125°C

@ I

F

= 5.0A, T

C

= +25°C

V

FM

0.55
0.65

0.65
0.75

V

Peak Reverse Current Maximum

@ T

C

= +25°C

at Rated DC Blocking Voltage (Note 6) @ T

C

= +125°C

I

RM

0.1

15

mA

Typical Total Capacitance (Note 7)

C

T

150 pF

Notes:

5. Device mounted on Device with additional heat sink (45mm X 20mm X 12mm), with minimum recommended pad layout per http://www.diodes.com

6. Short duration pulse test used to minimize self-heating effect.

7. Measured at 1.0 MHz and applied reverse voltage of 4.0V DC and per element.



0

2

4

6

8

10

0

50

100

150

I,

A

V

E

R

A

G

E

F

O

R

ZW

A

R

D

C

U

R

R

EN

T

(A

)

(A

V

)

T , CASE TEMPERATURE ( C)

Figure 1 Forward Current Derating Curve

C

°

Total Device

Per Element

I

, INS

TAN

TANE

O

U

S

F

O

R

WA

R

D

C

U

R

R

EN

T

(A

)

F

V , INSTANTANEOUS FORWARD VOLTAGE (V)

Figure 2 Typical Forward Characteristics, per Element

F

T = -55°C

J

MBR1030CT - MBR1045CT

100

0.2

0.4

0.6

0.8

10

0.1

0.01

1

T = 125°C

J

T = 100°C

J

T = 75°C

J

T = 150°C

J

T = 25°C

J
