Electrical Characteristics (continued)
@T
A
= 25°C unless otherwise specified
Type Number
Marking Code
Zener Voltage Range
(Note 6)
Maximum Zener Impedance
f = 1kHz
Maximum Reverse
Current (Note 7)
V
Z
@ I
ZT
I
ZT
Z
ZT
@
I
ZT
I
R
@
V
R
Min (V)
Max (V)
mA
Ω
μA
V
DDZ9V1ASF 4S
8.29
8.73
20 30 7.5
7.88
DDZ9V1BSF KS
8.57
9.01
20 30 7.5
8.14
DDZ9V1CSF YS
8.83
9.30
20 30 7.5
8.39
DDZ10ASF 4T
9.12
9.59
20
30
7.5
8.66
DDZ10BSF KT
9.41
9.90
20
30
7.5
8.94
DDZ10CSF YT
9.70
10.20
20
30
7.5
9.22
DDZ10DSF 7T
9.94
10.44
20
30
7.5
9.44
DDZ11ASF 4U
10.18
10.71
10
30
0.07
9.67
DDZ11BSF KU
10.50
11.05
10
30
7.5
9.98
DDZ11CSF YU
10.82
11.38
10
30
0.07
10.28
DDZ12ASF 4V
11.13
11.71
10
35
0.07
10.60
DDZ12BSF KV
11.44
12.03
10
30
0.07
10.90
DDZ12CSF YV
11.74
12.35
10
35
0.07
11.20
DDZ13ASF 4W
12.11
12.75
10
35
0.07
11.50
DDZ13BSF KW
12.55
13.21
10
35
0.07
11.90
DDZ13CSF YW
12.99
13.66
10
35
0.07
12.30
DDZ15ASF 4X
13.44
14.13
10
40
0.07
12.80
DDZ15BSF KX
13.89
14.62
10
40
0.07
13.20
DDZ15CSF YX
14.35
15.09
10
40
0.07
13.60
DDZ16ASF 4Y
14.80
15.57
10
40
0.07
14.10
DDZ16BSF KY
15.25
16.04
10
40
0.07
14.50
DDZ16CSF YY
15.69
16.51
10
40
0.07
14.90
DDZ18ASF 4Z
16.22
17.06
10
45
0.07
15.40
DDZ18BSF KZ
16.82
17.70
10
45
0.07
16.00
DDZ18CSF YZ
17.42
18.33
10
45
0.07
16.50
DDZ20ASF RJ
18.05
18.96
10
50
0.07
17.10
DDZ20BSF ZJ
18.63
19.59
10
50
0.07
17.70
DDZ20CSF PJ
19.23
20.22
10
50
0.07
17.70
DDZ20DSF 2J
19.72
20.72
10
50
0.07
18.70
DDZ22ASF RK
20.15
21.20
5
55
0.07
19.10
DDZ22BSF ZK
20.64
21.71
5
55
0.07
19.60
DDZ22CSF PK
21.08
22.17
5
55
0.07
20.00
DDZ22DSF 2K
21.52
22.63
5
55
0.07
20.40
DDZ24ASF RL
22.05
23.18
5
60
0.07
20.90
DDZ24BSF ZL
22.61
23.77
5
60
0.07
21.50
DDZ24CSF PL
23.12
24.31
5
60
0.07
22.00
DDZ24DSF 2L
23.63
24.85
5
60
0.07
22.40
DDZ27ASF RM
24.26
25.52
5
70
0.07
23.00
DDZ27BSF ZM
24.97
26.26
5
70
0.07
23.70
DDZ27CSF PM
25.63
26.95
5
70
0.07
24.30
DDZ27DSF 2M
26.29
27.64
5
70
0.07
25.00
DDZ30ASF RN
26.99
28.39
5
80
0.07
25.60
DDZ30BSF ZN
27.70
29.13
5
80
0.07
26.00
DDZ30CSF PN
28.36
29.82
5
55
0.07
26.90
DDZ30DSF 2N
29.02
30.51
5
80
0.07
27.60
DDZ33ASF RO
29.68
31.22
5
80
0.07
28.20
DDZ33BSF ZO
30.32
31.88
5
80
0.07
28.80
DDZ33CSF PO
30.90
32.50
5
65
0.07
29.40
DDZ33DSF 2O
31.49
33.11
5
65
0.07
29.90
DDZ36ASF RP
32.14
33.79
5
90
0.07
30.50
DDZ36BSF ZP
32.79
34.49
5
90
0.07
31.20
DDZ36CSF PP
33.40
35.13
5
75
0.07
31.70
DDZ36DSF 2P
34.01
35.77
5
90
0.07
32.30
DDZ39ASF RQ
34.68
36.47
5
85
0.2
30.00
DDZ39BSF ZQ
35.36
37.19
5
85
0.2
30.00
DDZ39CSF PQ
36.00
37.85
5
85
0.2
30.00
DDZ39DSF 2Q
36.63
38.52
5
85
0.2
30.00
Notes:
5. Device mounted on FR-4 PCB with 10mm x 10mm pad, board size 35mm * 25mm.
6. The Zener voltage is measured 40ms after power is supplied.
7. Short duration pulse test used to minimize self-heating effect.
