FZT591
Document number: DS33142 Rev. 4 - 2
4 of 7
December 2012
© Diodes Incorporated
FZT591
A Product Line of
Diodes Incorporated
Electrical Characteristics
(@T
A
= +25°C, unless otherwise specified.)
Characteristic Symbol
Min
Typ
Max
Unit
Test
Condition
Collector-Base Breakdown Voltage
BV
CBO
-80
−
−
V
I
C
= -100µA
Collector-Emitter Breakdown Voltage (Note 9)
BV
CEO
-60
−
−
V
I
C
= -10mA
Emitter-Base Breakdown Voltage
BV
EBO
-7 8.1
−
V
I
E
= -100µA
Collector Cut-off Current
I
CBO
−
<1 -100 nA V
CB
= -60V
Collector Cut-off Current
I
CES
−
<1 -100 nA V
CES
= -60V
Emitter Cut-off Current
I
EBO
−
<1 -100 nA V
EB
= -5.6V
Collector-Emitter Saturation Voltage (Note 9)
V
CE(sat)
−
−
-175
-350
-300
-600
mV
I
C
= -500mA, I
B
= -50mA
I
C
= -1A, I
B
= -100mA
Base-Emitter Saturation Voltage (Note 9)
V
BE(sat)
−
965
-1200 mV I
C
= -1A, I
B
= -100mA
Base-Emitter Turn-On Voltage (Note 9)
V
BE(on)
−
830
-1000 mV I
C
= -1A, V
CE
= -5V
DC current transfer Static ratio (Note 9)
h
FE
100
100
80
15
220
175
155
40
−
300
−
−
-
I
C
= -1mA, V
CE
= -5V
I
C
= -500mA, V
CE
= -5V
I
C
= -1A, V
CE
= -5V
I
C
= -2A, V
CE
= -5V
Transitional Frequency (Note 9)
f
T
150
−
−
MHz
V
CE
= -10V, I
C
= -50mA
f = 100MHz
Output Capacitance (Note 9)
C
obo
−
−
10 pF
V
CB
= -10V. f = 1MHz
Notes:
9. Measured under pulsed conditions. Pulse width ≤ 300µs. Duty cycle ≤ 2%
