Electrical Characteristics
(@T
A
= +25°C, unless otherwise specified.)
Characteristic Symbol Min Typ Max Unit Test Condition
Collector-Base Breakdown Voltage BV
CBO
100 300 - V I
C
= 100µA
Collector-Emitter Breakdown Voltage (Note 9) BV
CEO
100 130 - V I
C
= 1mA
Emitter-Base Breakdown Voltage BV
EBO
12 14 - V I
E
= 100µA
Collector-Base Cutoff Current I
CBO
- <10 100 nA V
CB
= 80V
Collector-Emitter Cutoff Current I
CES
- <10 200 nA V
CE
= 80V
Emitter Cutoff Current I
EBO
- <10 100 nA V
EB
= 7V
DC Current Gain (Note 9) h
FE
10,000
1,000
- - -
I
C
= 100mA, V
CE
= 5V
I
C
= 1A, V
CE
= 5V
Collector-Emitter Saturation Voltage (Note 9) V
CE(sat)
- - 1.5 V I
C
= 100mA, I
B
= 0.1mA
Base-Emitter Turn-On Voltage (Note 9) V
BE(on)
- - 2.0 V I
C
= 100mA, V
CE
= 5V
Output Capacitance (Note 9) C
obo
- 6.0 8.0 pF V
CB
= 10V. f = 1MHz
Current Gain-Bandwidth Product (Note 9) f
T
200 - - MHz V
CE
= 5V, I
C
= 100mA
Turn-On Time t
on
- 0.7 - µs V
CC
= 10V, I
C
= 100µA
I
B1
= -I
B2
= 0.1mA Turn-Off Time t
off
- 2.5 - µs
Notes: 9. Measured under pulsed conditions. Pulse width ≤ 300 µs. Duty cycle ≤ 2%.
