DRTR5V0U4SL
Document number: DS36222 Rev. 2 - 2
2 of 5
www.diodes.com
December 2013
© Diodes Incorporated
DRTR5V0U4SL
Maximum Ratings
(@T
A
= +25°C, unless otherwise specified)
Characteristic Symbol Value Unit Conditions
Peak Pulse Current I
PP
5 A 8/20 µs, Per Figure 2
ESD Protection – Contact Discharge V
ESD_Contact
±25 kV Standard IEC 61000-4-2
ESD Protection – Air Discharge V
ESD_Air
±30 kV Standard IEC 61000-4-2
Thermal Characteristics
Characteristic Symbol Value Unit
Power Dissipation (Note 5) P
D
200 mW
Thermal Resistance, Junction to Ambient (Note 5) R
θJA
625 C/W
Operating and Storage Temperature Range T
J
, T
STG
-65 to +150 C
Electrical Characteristics
(@T
A
= +25°C, unless otherwise specified)
Characteristic Symbol Min Typ Max Unit Test Conditions
Reverse Standoff Voltage V
RWM
—  — 5.5 V —
Channel Leakage Current (Note 6, 7) I
R
— 1 10 nA  V
R
= 2.5V
Reverse breakdown voltage V
BR
7.0 — 9.5 V I
R
= 1mA, from CH to GND
Clamping Voltage, Positive Transients V
CL
— 10.5 — V  I
PP
= 1A, t
p
= 8/20μs
— 12.5 — V I
PP
= 3A, t
p
= 8/20μs
Forward Voltage V
F
— 0.8 — V I
F
= 1mA
Dynamic Resistance R
DYN
— 0.8 —
Ω
I
TLP
= 10A to 20A, t
p
= 100ns, I/O
to GND
— 0.6 —
I
TLP
= 10A to 20A, t
p
= 100ns,
GND to I/O
I/O to GND Capacitance C
(I/O-GND)
— 0.8 1.2 pF V
(I/O-GND)
= 2.5V, f = 1MHz
Notes: 5. Device mounted on FR-4 PCB pad layout (2oz copper) as shown on Diodes, Inc. suggested pad layout AP02001, which can be found on our website at
http://www.diodes.com.
6. Short duration pulse test used to minimize self-heating effect.
7. Measured from pin 1, 2, 4, or 5 to GND.
8. For information on the impact of Diodes' USB 2.0 compatible ESD protectors on signal integrity including eye diagram plots, please refer to AN77 at the
following URL: http://www.diodes.com/destools/appnote_dnote.html.
0 125 175
150
50
100
0
T , AMBIENT TEMPERATURE ( C)
Figure 1 Power Derating Curve
A
°
P
,
P
O
WE
R
DI
S
S
IP
A
T
IO
N (
m
W
)
D
25 100 50 75 150
25
75
125
200
175
Note 5
0
50
25 50 75 100 125 150
P
EA
K
P
U
LS
E
D
E
R
A
T
IN
G
%
O
F
P
E
AK
PO
W
E
R O
R
CUR
R
ENT
T , AMBIENT TEMPERATURE (°C)
Figure 2 Pulse Derating Curve
A
0
100
25
75
175 200
