C-1 C-1 ACCESSORIES
4. KP666-035C Knurled Drive Roll (optional) —
Reversible Drive Roll with double knurled grooves
for .035 (0.9 mm) cored electrode.
5. K695-2 Spot / Stitch Timer Kit — Includes spot
timer to control the spot welding arc time, and a
stitch timer to control the on/off cycle time of the
arc to prevent burn through on thin gauge metals.
Also includes spot welding nozzle.
The Spot/Stitch Timer Kit installs inside the wire
feed compartment, replacing the blank panel locat-
ed below the gun trigger lead connectors, per the
installation instructions included with the kit.
6. K549-1 .035 (0.9 mm) Innershield Welding Kit
Includes a contact tip, a gasless nozzle and a cable
liner to permit the Magnum
™ 100L gun and cable
to use .035 ” (0.9 mm) diameter flux-cored elec-
trode. Also included is a spool of .035 (0.9 mm)
Innershield NR-211-MP.
OPTIONAL ACCESSORIES
1. K520 Utility Cart — Designed to transport the
Lincoln family of small welders. Has provisions for
mounting a single gas cylinder. Has front casters
and large rear wheels. Handle height is easily
adjustable. Bottom tray provided for tools and
accessories. Easy assembly required; takes less
than 15 minutes.
2. K586-1 Deluxe Adjustable Gas Regulator &
Hose Kit
Accommodates CO
2
or mixed Gas Cylinders.
3. K663-2 Aluminum Welding Kit — This kit
required for welding with .035 Aluminum wire.
Included with this kit are a drive roll, liner and con-
tact tip. It is important when changing between
welding with steel wire and aluminum to
exchange these components due to the lubri-
cant applied to steel wire. Failure to do so may
result in contaminated welds when welding alu-
minum.
See Maintenance section for instructions on
installing drive roll, cable liner, contact tip and their
proper configuration.
