MAINTENANCE
SAFETY PRECAUTIONS
ELECTRIC SHOCK can kill.
• Disconnect input power by
removing plug from receptacle
before working inside WELD-
MARK 135 PLUS. Use only
grounded receptacle. Do not
touch electrically
“ hot ” parts
inside WELDMARK 135 PLUS.
• Have qualified personnel do the
maintenance and trouble shoot-
ing work.
ITEMS REQUIRING NO
MAINTENANCE
• Drive Motor and Gearbox – Lifetime lubrication
• Fan Motor- Lifetime lubrication.
• Wire Reel Spindle – Do NOT lubricate shaft.
ROUTINE AND PERIODIC MAINTE-
NANCE
BEFORE EACH USE
• Check over machine and accessories for any obvi-
ous condition that may prevent safe performance or
operation, repair or replace items as necessary to
correct any abnormal condition.
AFTER 5 MINUTES OF WELDING
or when spatter accumulates in nozzle
• Clean nozzle to avoid bridging between nozzle and
contact tip which results in shorted nozzle, poor
welds and overheated gun. Hint: Anti-stick spray or
gel available from a welding supply distributor may
reduce buildup and aid in spatter removal.
AFTER EACH SPOOL OF WIRE FEED
• Remove contact tip and clean inside diameter with
short piece of wire
• Clean cable liner – when rough and erratic wire feed-
ing occur.
MAINTENANCE
D-1 D-1
WARNING
AFTER FEEDING 50# OF FLUX CORED
WIRE OR 300# OF SOLID WIRE
• Unplug machine or turn power switch to OFF – “ O ”
position. Remove gun and cable from machine.
• Remove gas nozzle and contact tip from gun.
• Lay cable out straight - blow out gently into gun end
with compressed air. Bend cable back and forth –
blow out again – Repeat until clean.
Excessive pressure at start may cause the dirt to
form a plug.
PERIODICALLY AS REQUIRED
• Blow dirt out of the welder with low pressure air to
eliminate excessive dirt and dust buildup that could
cause welder to run hot.
• Blow dirt out of: Rectifier & Fan Motor Assembly;
PC Board located on Case Side Assembly; and
Center Assembly components.
• Vacuum accumulated dirt from gearbox and wire
feed section.
• Inspect the incoming guide tube and clean inside
diameter if necessary. Replace when excessively
worn.
• Replace Contact Tip – when hole is enlarged or
elongated (refer to “ CHANGING THE CONTACT
TIP ” , in this section).
• Replace gas nozzle.
• Replace Liner – when wire feeding problems occur
and other items have been checked (refer to
“ CHANGING LINER ” procedure in this section).
• Replace internal gun handle parts as necessary
(see Procedure at the end of this section).
WARNING
WELDMARK 135 PLUS
