MT5HV11DC: #35087
REPLACEMENT PARTS LIST
Stock No.
Description
Qty.
93220
Vacuum Pump - Diaphragm Type - 1-SCFM [28 liters/minute] - 12 V DC (Dynaflo)
1
93214
Vacuum Control Valve w/Handle and Fittings (aka, vacuum package valve handle)
1
66197BM
Dynaflo Pump Gasket & Flap Valves
1
66197AM
Dynaflo Pump Diaphragm Kit
1
66197
Dynaflo Pump Head Assembly
1
66195
Thomas Pump Repair Kit (including diaphragm, head gasket and valve flappers)
1
66130
Vacuum Pump - Diaphragm Type - 1-SCFM [28 liters/minute] - 12 V DC (Thomas)
1
65430
Vacuum Hose - 7/32" [5.6 mm] ID (approx. 440" [1112 cm] in length)
1
65277
Vacuum Control Valve w/Lever
1
65211
Check Valve - 1/8 NPT
1
65014
Pad Spring - Wave Type
5
64707AS
Battery Charger - 240 V AC - Australian Type
1
64706AZ
Battery Charger - 240 VAC
1
64702AM
Battery Charger - 100 / 120 VAC
1
64664
Battery - 12 V DC - 7 Amp-Hours
1
64590
Battery Gauge
1
64460
Circuit Breaker - 15 A
1
64283
Bulb - 13 V - Bayonet (for low vacuum warning light)
1
64251
Red Indicator Light - 12 V DC (aka, low vacuum warning light)
1
64236
Vacuum Switch - 1/4 NPT
1
64230
Roller-Lever Switch
1
64200
Push-Button Switch (for battery test button)
1
54214
Foam Washer
1
54392
Battery Connector - Twin Lead
1
53132
Hose Fitting - Tee - 5/32" [4.0 mm] ID
2
53128
Pad Fitting - Tee - 5/32" [4.0 mm] ID
1
53122
Pad Fitting - Elbow - 5/32" [4.0 mm] ID
4
49614T
Vacuum Pad - Model HV11F / 10" [25 cm] Dia. - Lipped w/Foam Ring (option)
5
49605T
Vacuum Pad - Model HV11 / 10" [25 cm] Dia. - Lipped (standard)
5
49180
End Plug - 3" x 3" x 1/4" [76.2 mm x 76.2 mm x 6.4 mm] Tubing Size
2
49122
End Plug - 2" x 2" x 1/4" [50.8 mm x 50.8 mm x 6.4 mm] Tubing Size
4
49110
End Plug - 2" x 2" x 3/16" [50.8 mm x 50.8 mm x 4.8 mm] Tubing Size
2
29353
Pad Cover
5
20270
1/4" [6.4 mm] Open-End Wrench (for adjusting vacuum switch)
1
16134
Filter Element Kit (for 1.0 oz [30 ml] bowl size air filter)
1
16132
Filter Element Kit (for 4.4 oz [130 ml] bowl size air filter)
2
15910
Vacuum Gauge - 1/8 NPT - CBM Type
2
15630
Pad Filter Screen - Large
5
10900
Shoulder Bolt - Socket Head - 5/16" x 1/2" x 1/4-20 Thread (for mounting pads)
30
SERVICE ONLY WITH IDENTICAL REPLACEMENT PARTS
SUPPLIED BY OR APPROVED BY WOOD'S POWR-GRIP CO., INC.
