BOTTOM GASKET INSTALLATION

(CONTINUED)

4

Use a mallet to install the bottom gaskets on the door panels.

Fix Panel Side

Magnetic door gasket side

9

9

9

4c.

4c

INTERIOR

SHOWER SIDE

INTERIOR

SHOWER SIDE

INTERIOR

SHOWER SIDE
