Picture In Picture (PIP) Operation (Cont)
With a VCR - No Cable Box
This television includes a two tuner Picture In Picture (PIP) feature. This allows watching two
(2) live broadcasts at the same time without or with an external video source (VCR).
Connect your television to a VCR, as shown
TERMINALS ON BACK OF TV
VCR
Note:
The Remote Control must be programmed with the supplied codes to operate the
VCR, See Programming the Remote Control in the Remote Control Quick
Reference Guide.
Procedure
Press the PIP button on the Remote Control to display the PIP frame on screen.
Note:
The audio is from the Main Picture only.
To view an external video source in the PIP frame:
•
Press the TV/VIDEO button on the Remote Control to select the same video
input to which your VCR is connected.
•
Verify the VCR is on.
•
Choose channels for the Main Picture by pressing the TV button on the Remote
Control and using the numeric keypad or CH up/down button.
•
Choose channels for the PIP frame by pressing the TV button on the Remote
Control and using the PIP Channel up/down buttons.
The SWAP button switches the PIP and
Main Picture source. Press the RECALL
button for on screen PIP and Main Picture
source status.
©
