CONTROL PANEL PARTS
For Model: CAM2752TQ0
(White)
lus.
No.
Part
No.
DESCRIPTION
Illus.
Part
No. No.
DESCRIPTION
Illus.
No.
Part
No.
DESCRIPTION
1
8577883 Panel, Console
10
3348109 Lens, Amber (2)
19 W10114216 Harness, Wiring
2
3978858 Bracket, Control
11
3348110 Lens, Yellow (l)
(Includes
3
3349494 Connector, ATC
12
8316433 Pushbutton (7)
Items 20 & 21)
4
8577359 Switch, Cycle
13
8524802 Pressure Switch,
(For Detail See
Selector
Low Water Level
Pages 12 & 13)
(Includes Item 12)
14
3400073 Screw, 10-24 x 3/8
20
8524801 Hose, Pressure
5
3390646 Screw, 8-18 X 5/16
15
90767 Screw,
Switch to Air Dome
6
3949740 End Cap (R.H.)
8-18 x 3/8 (2)
21
8524791 Hose, Pressure
7
8281182 Screw (2)
16
3949734 End Cap (L.H.)
Switch Link
8
8573825 Pressure Switch,
17
689559 Nut, Push-In (2)
22
357572 Clip, Grounding
High Water Level
18
97787 Screw, End Cap
23
8578168 Control,
(Includes "T"
To Bracket (4)
Automatic Temp.
Fitting-Not Shown)
(ATC)
9
3352457 Lights, Indicator
W10114744
FOR ORDERING INFORMATION REFER TO PARTS PRICE LIST
