E14
NAC 282, NAC 202 & NAC 152 XS
12.3 NAC 202 Connected to Hi-Cap and NAPSC
12.4 NAC 152 XS Connected to FlatCap (both outputs)
mains input
and fuse
to stereo power amplifier
to mono or dual
mono power
amplifiers
additional
signal output
mains input
and fuse
power
switch
to stereo
power amplifier
to mono or dual
mono power
amplifiers
additional signal
output
cable
direction
marker
Interconnect Cables
240° 5 to 5 pin DIN
