Lenco DVP-9412 - Manual (Page 15)

USB
To access the Menu, press the Menu button and select USB.
Multi-Media
Switch to USB mode and plug in USB to view files.
Multimedia
Photo Configure
USB
Confirm Return OK EXIT
Troubleshooting
The image stopped
suddenly or mosaic
Problem Potential Reasons What to do
No picture Power isn't connected Connect the power
The power switch
is not on
Switch on the power
Screen shows
No Signal
DVB-T cable not Plug in the DVB-T cable
Incorrect setting Reset setting
No sound from
speaker No or incorrect connection
with audio cable
Connect the audio
correctly
Sound on mute Turn off mute function
Incorrect sound track Try another sound track
Only sound, no
image on the
screen No or incorrect connection
with AV cable Make sure cables
connected correctly
The program is a radio
program Press <TV/RADIO> key
shift into TV mode
Remote Control
is not responding The battery is exhausted Change battery
Remote Control is not
facing or close enough
to the Set Top Box Adjust the position
Remote Control and
closer to the unit
The signal is too weak Strengthen the signal
cable
are
to
of the
move
connected
14
First Time Installation
Technical Specifications
Video
Decoder Format
MPEG4 AVC/H.264 HP@L4
MPEG2 [email protected]
Output Format 576P , 720P, 1080i, 4:3 and 16:9
Output Port HDMI
Item Sub Item Parameter
Tuner
Input Frequency 170~230MHz
470~860MHz
RF Input level -25~-82dBm
IF Bandwidth 7MHz and 8MHz
Modulation QPSK,16QAM,64QAM
Movie Configure
