60 Instruments and controls
Main instrument panel Warning and
indicator lights
A number of warning and indicator lights will
come on when the ignition is switched on
prior to starting (see page 65). Under
normal conditions, these should go out a
few seconds after the engine has started.
Warning, oil pressure (en-
gine oil)
This symbol comes on together with if
the oil pressure in the engine is too low. If
the symbol flashes or comes on while you
are driving, stop as soon as possible and
where it is safe to do so, switch off the
engine and check the engine oil level, see
page 196.
NOTE
The car must not be driven under any cir-
cumstances when the warning lamp is on.
Too low oil pressure will damage the
engine.
20
30
40
50
60 70
80
90
100
110
120
130
140 150
240 220
200
180
160
140
120 100
80
60
40
20
10
9
4 5 3 2
7 8 6
1
IB1690
Main instrument panel
1 Tachometer
2 Indicator and warning lights
3 Speedometer
4 Indicator and warning lights
5 Pressure gauge 6 Fuel gauge
7 Engine temperature gauge
8 Trip meter reset button
9 Odometer and trip meter
