APPENDIX:
9.1. Data Identification Word of Ancillary Data Packet
ANC Data
DID
SDID / DBN
352M
0x41
0x01
RP-165-EDH*
0xF4
0x00
● Data Type 1(SMPTE-291M)
9.2. Built-in Video Patterns
SMPTE Bar
100% Bar
Check Field
EQ
PLL
Gradient R1
Gradient G1
Gradient B1
Gradient R2
Gradient G2
Gradient B2
Gradient R3
Gradient G3
Gradient B3
