PANEL DESCRIPTION:
6.1. Bird's View
AT-3GSDI500
+5V DC
3G/HD/SD-SDI
OUTPUT
A
3G/HD/SD-SDI
OUTPUT
B
HDMI
INPUT UP
DOWN
M
E
N
U
E
N
T
E
R
Button Function
Menu Trigger the function menu
Enter Enter the menu item
Up Choose the last menu item
Down Choose the next menu item
6.2. Input Panel
1 2
1. HDMI TH INPUT: Plug in a HDMI TH cable to be linked to a HDMI TH source
2. +5V DC: Connect to a 5V DC power supply unit
