FS-97B User’s Manual Hardware Setup
Onboard Display Interface
20
2.8 <Onboard Display Interface>
Based on Intel Q965 chipset with built-in graphics, the board provides one DB15 connector
on real external I/O port, and one 40-pin LVDS interface with 5-pin LCD backlight inverter
connector. (FS-97BXG/ XG2 Only)
The board also provides 26-pin DVI interface. (FS-97BDG/ DG2 Only )
2.8.1 <Analog Display>
Please connect your CRT or LCD monitor with DB15 male connector to the onboard DB15
female connector on bracket.
CRT
