FS-97C User’s Manual Hardware Setup
Connector Location
12
PS2 RJ45_2 RJ45_1 CRT
Chapter 2 <Hardware Setup>
2.1 <Connector Location>
SYSFAN
CN_IR
IDE
CN_LVDS
MINIPCI2
CDIN
CN AUDIO
CN_DIO
SATA1/2
JFRNT
CN_PS
DC_IN
CN_HDTV
CN_COM1/2
CPUFAN
CN_USB1/2
CN_DVI
FDD
CF
MINIPCI1
CN_INV
CN_ATKB
CN_LPT
DDRII_A/B
