PMSA User’s Manual
-
13
-
2.2 <Jumper Location & Reference>
Jumper
Function
JRTC
CMOS Operating/Clear Setting
JCFSEL
CF mode selection
JVLCD
Panel Voltage Setting
JP1
COM1 signal mode switch (For Pin-1 & Pin-9)
JP2
COM2 signal mode switch (For Pin-1 & Pin-9)
JAT
Power mode select
JCFSEL
JVLCD
JAT
JCSEL1
JP1
JP2
JRTC
JCSEL2
