LV-67A User’s Manual
12
PS2
Chapter 2 <Hardware Setup>
2.1 <Connector Location>
CN_12V
CN_DVI1
CPUFAN
CN_COM4
CN_DIO
FDD
SYSFAN
JFRNT
CN_USB
CN_AUDIO
SPDIF
CDIN
CN_IR
ATX
COM1 + CRT
USB_RJ45_1/2
Audio
DDRIIIA/B
S_ATA1~6
PCI
Mini-PCI
COM2+COM3
CN_DVI2
CN_SMBUS
CN_USB4
JAT
JCSEL2
JCSEL1
JP1/JP2
